| RM 1902년, 쉬운 빌딩, 253-261 헤네시 길, 완차이, 홍콩 | jason@hydraulicpumpvalve.com |
 |
| 원래 장소: | 독일 |
| 브랜드 이름: | Rexroth |
| 모델 번호: | R909609230 AA11VLO130DRS/10R-NSD62N00 |
| 최소 주문 수량: | 1 |
|---|---|
| 가격: | On Request |
| 포장 세부 사항: | 표준 나무 상자 |
| 배달 시간: | 7-10days |
| 지불 조건: | T/T, 서부 동맹 |
| 공급 능력: | 1000/month |
| MNR: | R909609230 | 모델: | AA11VLO130DRS/10R-NSD62N00 |
|---|---|---|---|
| 강조하다: | 렉스로스 축 방향 피스톤 변량펌프,R909609230,경사판 렉스로스 유압펌프 |
||
Rexroth A11VO Series Axial Piston Variable Pump
Features
Through drive for mounting of further pumps up to same nominal size
Optional with charge pump for the nominal sizes 130…260
Particularly high speeds are possible with impeller pump version (A11VLO)
Large variety of controls
Swashplate design
| Size | 40 | 60 | 75 | 95 | 130 | 145 | 190 | 260 | 130 | 145 | 190 | 260 | |||
| Version | Standard | With charge pump | |||||||||||||
| Displacement geometric, per revolution |
Vg max | cm³ | 42 | 58.5 | 74 | 93.5 | 130 | 145 | 193 | 260 | 130 | 145 | 193 | 260 | |
| Nominal pressure | pnom | bar | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
| Maximum pressure | pmax | bar | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | |
| Maximum speed | at Vg max | nnom | rpm | 3000 1) | 2700 1) | 2550 1) | 2350 1) | 2100 1) | 2200 1) | 2100 1) | 1800 1) | 2500 2) | 2500 2) | 2500 2) | 2300 2) |
| Flow | at Vg max and nnom | qV nom | l/min | 126 | 158 | 189 | 220 | 273 | 319 | 405 | 468 | 325 | 363 | 483 | 598 |
| Power | at qV nom and pnom | P | kW | 74 | 92 | 110 | 128 | 159 | 186 | 236 | 273 | 190 | 211 | 281 | 349 |
| Torque | at Vg max and pnom | M | Nm | 234 | 326 | 412 | 521 | 724 | 808 | 1075 | 1448 | 724 | 808 | 1075 | 1448 |
| Weight (approx.) | m | kg | 32 | 40 | 45 | 53 | 66 | 76 | 95 | 125 | 72 | 73 | 104 | 138 | |
| R902012401 | A11VLO130DRS+A11VLO130DRS |
| R902076949 | A11VLO130DRS+A11VLO130DRS |
| R902061280 | A11VLO130DRS+A11VO60DRS |
| R902196050 | A11VLO130DRS+LA10VO71DRF+LA10VO28DR |
| R902042675 | A11VLO130DRS/10L-NPD12N00 |
| R902032788 | A11VLO130DRS/10L-NSD12K01 |
| R902089798 | A11VLO130DRS/10L-NSD12K01-K |
| R902186852 | A11VLO130DRS/10L-NSD12K01-S |
| R902251709 | A11VLO130DRS/10L-NSD12K02 |
| R902011235 | A11VLO130DRS/10L-NSD12K02 |
| R902129462 | A11VLO130DRS/10L-NSD12K02-S |
| R902235163 | A11VLO130DRS/10L-NSD12K02-S |
| R902041111 | A11VLO130DRS/10L-NSD12K02-S |
| R992001611 | A11VLO130DRS/10L-NSD12K02-S |
| R902251811 | A11VLO130DRS/10L-NSD12K02-S |
| R902208981 | A11VLO130DRS/10L-NSD12K02-Y |
| R902227574 | A11VLO130DRS/10L-NSD12K04 |
| R902257928 | A11VLO130DRS/10L-NSD12K04 |
| R902034912 | A11VLO130DRS/10L-NSD12K04 |
| R902220559 | A11VLO130DRS/10L-NSD12K04 |
| R902048239 | A11VLO130DRS/10L-NSD12K04-S |
| R902245792 | A11VLO130DRS/10L-NSD12K04-Y |
| R902030417 | A11VLO130DRS/10L-NSD12K07 |
| R902237253 | A11VLO130DRS/10L-NSD12K07 |
| R902085866 | A11VLO130DRS/10L-NSD12K07-S |
| R902076947 | A11VLO130DRS/10L-NSD12K17 |
| R902220560 | A11VLO130DRS/10L-NSD12K17 |
| R902129460 | A11VLO130DRS/10L-NSD12K17-S |
| R902237400 | A11VLO130DRS/10L-NSD12K86 |
| R902028119 | A11VLO130DRS/10L-NSD12N00 |
| R902204693 | A11VLO130DRS/10L-NSD12N00 |
| R902211977 | A11VLO130DRS/10L-NSD12N00 |
| R902239798 | A11VLO130DRS/10L-NSD12N00 |
| R902076948 | A11VLO130DRS/10L-NSD12N00 |
| R902237126 | A11VLO130DRS/10L-NSD12N00 |
| R902233548 | A11VLO130DRS/10L-NSD12N00 |
| R902071682 | A11VLO130DRS/10L-NSD12N00-S |
| R902051098 | A11VLO130DRS/10L-NZD12K01 |
| R902100630 | A11VLO130DRS/10L-NZD12K02 |
| R902012405 | A11VLO130DRS/10L-NZD12K83 |
| R902248379 | A11VLO130DRS/10L-NZD12N00 |
| R902012409 | A11VLO130DRS/10L-NZD12N00 |
| R902009188 | A11VLO130DRS/10L-NZD12N00-S |
| R902014982 | A11VLO130DRS/10R-NPD12N00 |
| R902235326 | A11VLO130DRS/10R-NSD12K01 |
| R902170396 | A11VLO130DRS/10R-NSD12K01 |
| R902013875 | A11VLO130DRS/10R-NSD12K01 |
| R902118170 | A11VLO130DRS/10R-NSD12K01V |
| R902255663 | A11VLO130DRS/10R-NSD12K01V |
| R909608299 | A11VLO130DRS/10R-NSD12K02 |
| R902100962 | A11VLO130DRS/10R-NSD12K02V |
| R902220503 | A11VLO130DRS/10R-NSD12K04 |
| R902042666 | A11VLO130DRS/10R-NSD12K04 |
| R902018924 | A11VLO130DRS/10R-NSD12K07 |
| R902165469 | A11VLO130DRS/10R-NSD12K07 |
| R902220504 | A11VLO130DRS/10R-NSD12K17 |
| R902019778 | A11VLO130DRS/10R-NSD12K17 |
| R902041112 | A11VLO130DRS/10R-NSD12K17-S |
| R902194891 | A11VLO130DRS/10R-NSD12K86 |
| R902233921 | A11VLO130DRS/10R-NSD12K86 |
| R909608217 | A11VLO130DRS/10R-NSD12N00 |
| R902197867 | A11VLO130DRS/10R-NSD12N00 |
| R902046584 | A11VLO130DRS/10R-NSD12N00-S |
| R902066278 | A11VLO130DRS/10R-NSD12N00-S |
| R902204854 | A11VLO130DRS/10R-NZD12K01 |
| R902080449 | A11VLO130DRS/10R-NZD12K01 |
| R902235165 | A11VLO130DRS/10R-NZD12K02 |
| R902138967 | A11VLO130DRS/10R-NZD12K02 |
| R902277289 | A11VLO130DRS/10R-NZD12K02 |
| R902138965 | A11VLO130DRS/10R-NZD12K02-K |
| R902062586 | A11VLO130DRS/10R-NZD12K04 |
| R902008059 | A11VLO130DRS/10R-NZD12K07 |
| R902233473 | A11VLO130DRS/10R-NZD12K17 |
| R902170303 | A11VLO130DRS/10R-NZD12K17 |
| R902067107 | A11VLO130DRS/10R-NZD12K17 |
| R902233760 | A11VLO130DRS/10R-NZD12N00 |
| R902170593 | A11VLO130DRS/10R-NZD12N00 |
| R909447910 | A11VLO130DRS/10R-NZD12N00 |
| R902092524 | A11VLO130DRS/10R-NZD12N00-E |
| R902105352 | AA11VLO130DRS+AA11VLO130DRS |
| R902198846 | AA11VLO130DRS/10L-NSD62K01 |
| R902046546 | AA11VLO130DRS/10L-NSD62K02 |
| R902046954 | AA11VLO130DRS/10L-NSD62K04 |
| R902103928 | AA11VLO130DRS/10L-NSD62K04-S |
| R902018580 | AA11VLO130DRS/10L-NSD62K07 |
| R902235477 | AA11VLO130DRS/10L-NSD62K07 |
| R909606879 | AA11VLO130DRS/10L-NSD62N00 |
| R902092077 | AA11VLO130DRS/10L-NSD62N00-E |
| R902092221 | AA11VLO130DRS/10L-NSD62N00-ES |
| R902092349 | AA11VLO130DRS/10L-NSD62N00-ES |
| R902066212 | AA11VLO130DRS/10L-NSD62N00-S |
| R902205934 | AA11VLO130DRS/10L-NSD62N00-S |
| R902205696 | AA11VLO130DRS/10L-NSD62N00-S |
| R902081074 | AA11VLO130DRS/10L-NSD62N00-S |
| R902037874 | AA11VLO130DRS/10L-NSD62N00-S |
| R902237133 | AA11VLO130DRS/10R-NSD07K02 |
| R902062566 | AA11VLO130DRS/10R-NSD62K02 |
| R902092333 | AA11VLO130DRS/10R-NSD62K02-ES |
| R902062615 | AA11VLO130DRS/10R-NSD62K02-S |
| R902032046 | AA11VLO130DRS/10R-NSD62K02-S |
| R902064183 | AA11VLO130DRS/10R-NSD62K02-S |
| R902235329 | AA11VLO130DRS/10R-NSD62K04 |
| R902008603 | AA11VLO130DRS/10R-NSD62K04 |
| R902005936 | AA11VLO130DRS/10R-NSD62K07 |
| R902239559 | AA11VLO130DRS/10R-NSD62K07 |
| R902232927 | AA11VLO130DRS/10R-NSD62K07 |
| R902205693 | AA11VLO130DRS/10R-NSD62K17 |
| R902070267 | AA11VLO130DRS/10R-NSD62K17 |
| R902205730 | AA11VLO130DRS/10R-NSD62K17 |
| R902205731 | AA11VLO130DRS/10R-NSD62K86 |
| R902208128 | AA11VLO130DRS/10R-NSD62K86 |
| R902205506 | AA11VLO130DRS/10R-NSD62N00 |
| R902205732 | AA11VLO130DRS/10R-NSD62N00 |
| R909609230 | AA11VLO130DRS/10R-NSD62N00 |
| R902205507 | AA11VLO130DRS/10R-NSD62N00 |
| R902232618 | AA11VLO130DRS/10R-NSD62N00 |
| R902092081 | AA11VLO130DRS/10R-NSD62N00-E |
| R902092080 | AA11VLO130DRS/10R-NSD62N00-E |
| R902092079 | AA11VLO130DRS/10R-NSD62N00-E |
| R902067193 | AA11VLO130DRS/10R-NSD62N00-S |
| R902034864 | AA11VLO130DRS/10R-NSD62N00-S |
| R902092508 | AA11VLO130DRS/10R-NSD62N00-S |
